CC-379

Name: CC-379 ISA 4 Port RS232 DB25 - Brainboxes
SKU: CC-379
Price: 290.25 USD
Availability: InStock

ISA 4 Port RS232 DB25

Discontinued

A half size card provides 4 industry standard RS232 serial ports in a single slot with 4 DB25 connectors. A fully moulded Quad cable terminated in either 9 or 25 pin male ‘D’ plugs ensures neat & easy connections. Serial Solutions Device Driver CD contains software for Windows Millennium, Windows 98, Windows 95, Windows NT4, Windows 3.x, DOS and OS/2. Informative manuals and sample programs are supplied with full source code on CD!

Serial Port
Serial Port	Ports	4
	Protocol	RS232
	Connector	DB25 Connector - 25 Pin Male
	UART	TI 550
	UART Compatibility	16750/16550/16450 backwards compatibile
	Tx FIFO Size	16
	Rx FIFO Size	16
	Operating Distance	EIA - RS232 Standard
	Cable	4 port cable (44 way D to 4x25 Pin Male)
Serial Port Settings
Serial Port Settings	Max Baud Rate	115,200
	Data Bits	5,6,7 or 8
	Parity	Odd, Even, None, Mark or Space
	Stop Bits	1 or 2
	Tx/Rx Modes	Point to Point
General
General	PCB Layers	4
	Form Factor	Standard Height
	Includes Printer Port	No
	Galvanic Isolation	No
	Power Consumption	575mA @ 5V, 70mA @ 12V
	Product Weight	0.118 kg
	Product Dimensions	awaiting
	Packaged Weight	awaiting
	Packaged Dimensions	awaiting
	GTIN (barcode)
Operating System Compatibility
Operating System Compatibility	Operating Systems	Microsoft Windows ME Microsoft Windows 98 Microsoft Windows NT 4.0 Microsoft Windows 95 Microsoft Windows 3.x OS/2 DOS
Interface
Interface	ISA	Industry Standard Architecture
