CC-500
IDC-MM to RJ45 30cm 10/100 Cable Pack of 5Key Specs
- IDC-Style to RJ45
- 30cm Length
- Pack of 5
- Supports 10/100 Ethernet
- Provides direct connectivity for your Pure Embedded (PE) devices
(22)
CC-510
CC-510 IDC-MM to RJ45 30cm Gigabit Cable Pack of 5Key Specs
- IDC-Style to RJ45
- 30cm Length
- Pack of 5
- Supports 10/100/1000 Ethernet
- Provides direct connectivity for your Pure Embedded (PE) devices
CC-869
Screw Terminal Wired 9 Pin D ConnectorKey Specs
The CC-869 is suitable for wiring Screw Terminal connections into a standard 9 Pin D connector, ideal for quick but secure solderless connections in the field. Many industries use stripped wire screw terminals as the de facto connection method. This adapter enables devices with the ubiquitous 9 pin male D to be used in these situations.
MK-048
DIN-RAIL MOUNTING KIT/CLIP FOR 1 & 2 PORT ES/US and SW-005Key Specs
- DIN Rail mount Brainboxes 1 & 2 port USB and Ethernet products as well as SW-005
- Simple installation
- Light Weight
- Mounts enclosures to 35 mm and 32mm wide DIN rails
- Conforms to IEC International Standard 60715
- Conforms to European Standard EN 50022
MK-059
WALL MOUNTING KIT FOR ES/US 4&8 PORT - RETAIL PACKKey Specs
- Wall Mounting Kit For ES/US 4&8 Port Devices
- Simple installation
- 2 Fitting options: fixed or detachable
- Light Weight
- Can be mounted to any flat surface
- Screws to attach to device included
MK-070
SNAP IN DIN-RAIL CLIP KIT FOR ES/US 4 and 8 PORT - RETAIL PACKKey Specs
- DIN Rail mount Brainboxes 4 & 8 port USB and Ethernet products
- Simple installation
- Light Weight
- Mounts enclosures to 35 mm and 32mm wide DIN rails
- Conforms to IEC International Standard 60715
- Conforms to European Standard EN 50022
MK-081
22.5mm Modular Device Wall/ Surface Mounting Clip - Cabinet Space SaverKey Specs
- Mounts 22.5mm modular devices to any wall/surface
- Mount at any orientation
- Secure fit
- Simple installation
- Save cabinet space
MK-092
22.5 MM MODULAR DEVICE RIGHT ANGLE DIN RAIL MOUNTING CLIP - CABINET SPACE SAVERKey Specs
- Mount to DIN-rail at any orientation
- Simple installation
- Secure fit
- Save cabinet space
- Conforms to IEC International Standard 60715
- Conforms to European Standard EN 50022
MK-103
SPRING LOADED DIN RAIL MOUNT 20MM WIDTHKey Specs
- Spring loaded DIN-rail mount
- Simple installation
- Light Weight
- Mounts enclosures to 35 mm and 32mm wide DIN rails
- Conforms to IEC International Standard 60715
- Conforms to European Standard EN 50022
MK-114
SPRING LOADED DIN RAIL MOUNT 35MM WIDTHKey Specs
- Spring loaded DIN-rail mount
- Simple installation
- Light Weight
- Mounts enclosures to 35 mm and 32mm wide DIN rails
- Conforms to IEC International Standard 60715
- Conforms to European Standard EN 50022
MK-588
6 PACK ED-5XX/ ES-5XX 5-WAY 3.5MM PITCH PLUGGABLE BLOCKS - RETAIL PACKKey Specs
- 6 coloured PCB connectors
- Individually numbered pins – simplify wiring
- 5 x 3.5mm pitch
- Screw connections with tension sleeve
MK-923
Raspberry Pi Compute Module Heatsink AccessoryKey Specs
- Compatible with CM 3+, CM3 Lite, CM3 and CM1 (use additional included thermal pad)
- Sits in direct contact with the Raspberry Pi compute module’s integrated processing chip (SoC)
- Includes: 2x M1.6 & 2x M2.0 screws and nuts, spare heat pad, and heatsink
- Used by Brainboxes in the BB-400 and BB-411.
PW-245
60W Single Output Industrial DIN Power SupplyKey Specs
- Mains input Voltages: installed by qualified electricians only
- Universal 85-264VAC or 120-370VDC input Voltage
- Output: +24VDC, 2.5A, 60W
- Operating temperature range: -40ºC to +70ºC/-40ºF to 158ºF
- High I/O isolation test Voltage up to 4000VAC
- Over-voltage class III (Designed to meet EN61558-1 safety standards)
- Output short circuit, over-current, over-Voltage protection
PW-301
96W Single Output Industrial DIN Power SupplyKey Specs
- Mains input Voltages: installed by qualified electricians only
- Input Voltage 100VAC to 240VAC
- Output: +48VDC, 1.92A, 92.16W
- Operating temperature range: -10ºC to +40ºC
- Protections: Short Circuit/Overload/Over Voltage
PW-400
Power Adapter 12V 1.5A Terminal Tails UK/EU/US/AUS PackKey Specs
- Suitable for Brainboxes BB-400 Smart Controller
- 2 Terminal Tails
- OUTPUT: 12V DC 1.5A
- Plug fittings cover 189 countries world wide
- Including the EU, USA, UK and Australia
- UL Approved, CE Approved, RoHS Compliant
PW-500
Power Adaptor 5V 3A 2.1mm Screw Lock UK/EU/US/AU Retail PackKey Specs
- Suitable for Brainboxes US-346, US-279 and US-842
- 2.1mm Screw Lock Terminal
- OUTPUT: 5V DC 3A
- Plug fittings cover 189 countries world wide
- Including the EU, USA, UK and Australia
- VW-1 Rated, UL Approved, CE Approved, RoHS Compliant
PW-600
Power Adapter 5V 1.2A Terminal Tails UK/EU/US/AUS Retail PackKey Specs
- Suitable for Brainboxes ES-357 and Industrial Ethernet Devices
- 2 Terminal Tails
- OUTPUT: 5V DC 1.2A
- Plug fittings cover 189 countries world wide
- Including the EU, USA, UK and Australia
- VW-1 Rated, UL Approved, CE Approved, RoHS Compliant
PW-623
USB Power Cable to 3 pin Terminal PlugKey Specs
- Power 3-pin terminal block via 1.8m/6ft USB
- Use with Brainboxes ED-004, ED-008, ED-038, ED-204, ES-020, ES-357, SW-005.
- RoHS Compliant
- PoE enables non-PoE devices
PW-650
USB to 5 Pin Terminal Block Power AdapterKey Specs
- Suitable for Brainboxes Industrial Ethernet Devices
- Power ED and ES devices from any USB port
- Perfect for preconfiguring devices before deploying in the field
- USB at one end, 5 pin terminal block at the other
- Cable length 1.8 m (6 ft)
PW-800
Power Adapter 5V 1.2A 4mm Tip UK/EU/US/AUS - Retail PackKey Specs
- Suitable for Brainboxes ES-246, ES-257, ES-313, US-346
- 4mm Tip Terminal
- OUTPUT: 5V DC 1.2A
- Plug fittings cover 189 countries world wide
- Including the EU, USA, UK and Australia
- VW-1 Rated, UL Approved, CE Approved, RoHS Compliant
US-045
USB Type A plug to A receptacle 0.25m Cable for US-101/324Key Specs
USB 2.0 Type A Male plug on a cable 250mm long to Type A Female receptacle
US-063
USB Type A Plug to Type B Plug 1000mmKey Specs
USB 2.0 Type A Male Plug on a cable 1000mm long to Type B Male Plug 1000mm
Whether you are upgrading factory automation systems, integrating IIoT (Industrial Internet of Things) devices, or connecting remote monitoring equipment, our switches provide the robust network backbone your mission-critical applications require.
Engineered for resilience, our portfolio includes Fast Ethernet, Gigabit Ethernet, and PoE+ (Power over Ethernet) options to suit varying bandwidth and power needs. Built to withstand extreme conditions on the factory floor, these unmanaged switches feature wide operating temperature ranges (from -40°C to +80°C), dual redundant power inputs, and highly efficient low power consumption.
We understand that industrial physical space is often at a premium. Choose from compact, DIN-rail mountable enclosures for standard control cabinets, wall-mountable units for light industrial spaces, or bare-board embeddable switches designed specifically for OEM integration. For extended fiber optic reach, we also provide gigabit SFP media converters.
As a trusted UK manufacturer with decades of engineering expertise, Brainboxes stands behind the quality of our connectivity solutions. All our industrial network switches are backed by an industry-leading lifetime warranty and free, highly-qualified lifetime technical support.
