XC-157

1 LPT Printer Port Native ExpressCard

Discontinued

1 LPT Printer Port
ExpressCard (PCIe) Technology
34mm wide ExpressCard fits 34mm or 54mm slots
Drivers for all popular operating systems
Lifetime Warranty
Lifetime Support

ExpressCard providing one Printer port. ExpressCard is 34mm wide and fits 34mm or 54mm slots. Where absolute compatibility with classic desktop LPT parallel printer ports is a necessity. Guaranteed low latency, memory mapped, no compromise high performance interface. Drivers for Windows 32 bit and 64 bit Operating Systems including Windows XP, Server 2003, Vista, Server 2008, Windows 7, 8 and Windows 10.

Serial Port
Serial Port	Ports	1
	Protocol	LPT Printer
	Connector	25 Pin Parallel Port Female Connector
	Tx FIFO Size	128
	Rx FIFO Size	128
	Operating Distance	EIA - RS232 Standard
	Cable	25 Pin D-sub female
Serial Port Settings
Serial Port Settings	Max Baud Rate	921,600
	Data Bits	5,6,7 or 8
	Parity	Odd, Even, None, Mark or Space
	Stop Bits	1 or 2
	Flow Control	RTS/CTS, DSR/DTR, XON/XOFF
	Tx/Rx Modes	Point to Point
General
General	Ruggedised	No
	PCB Layers	4
	ExpressCard Width	34mm (fits both 34mm and 54mm ExpressCard slots)
	Power Consumption	40mA @ 3.3V
	Product Weight	0.043 kg
	Product Dimensions	110(l) x 46(w) x 20(h) mm
	Packaged Weight	0.29 kg
	Packaged Dimensions	160(l) x 135(w) x 49(h) mm
	GTIN (barcode)	837324002331
Operating System Compatibility
Operating System Compatibility	Operating Systems	Microsoft Windows 10 Microsoft Windows 8 32 bit & 64 bit Editions Microsoft Windows 7 32 bit & 64 bit Editions Windows Vista 32 bit & 64 bit Editions Windows XP 32 bit & 64 bit Editions
Interface
Interface	ExpressCard PCIe Implementation	ExpressCard PCIe Implementation. Unlike the VX range which uses USB technology over ExpressCard, this uses PCI Express technology over ExpressCard. All Brainboxes XC cards are PCI Express Base Specification 1.1 Compliant.
