PX-263

Name: PX-263 4xRS232 PCIe Serial Port Card with LPT Parallel Port for Printer Low profile - Brainboxes
SKU: PX-263
Price: 393.53 USD
Availability: InStock

4xRS232 PCIe Serial Port Card with LPT Parallel Port for Printer Low profile

PDF Datasheet Download

$393.53

Add to Cart

Buy from Reseller

Volume Purchase?Request a Quote

windows-server-2003-32-bit-64-bit-editions

windows-server-2008-32-bit-64-bit-editions

PCI Express Card providing four RS232 serial ports and one LPT port (4 industry standard 9 pin D RS232 ports via a quad cable plus a 25 pin D LPT port on a flylead). Brainboxes’ own BB16C958 UART provides data transfer rates up to 921,600 baud rates and the 128 byte deep transmit and 128 byte receive FIFOS, coupled with 1Mbit/s line drivers deliver uncompromising performance on your PC. Drivers for Windows 32 bit and 64 bit Operating Systems including Windows 2000, XP, Server 2003, Vista, Server 2008, Windows 7, Windows 8 & Windows 10 and Linux.

Serial Port
Serial Port	Ports	4 x RS232 + 1 x LPT Printer
	Protocol	RS232 + LPT Printer
	Connector	DB9 Connector (9 Pin Male) and LPT port (25 Pin Female)
	UART	Oxford 950
	UART Compatibility	16750/16550/16450 backwards compatibile
	Tx FIFO Size	128
	Rx FIFO Size	128
	Operating Distance	EIA - RS232 Standard
	Cable	4 port cable (44 way D to 4x9 Pin Male)
Serial Port Settings
Serial Port Settings	Max Baud Rate	921,600
	Data Bits	5,6,7 or 8
	Parity	Odd, Even, None, Mark or Space
	Stop Bits	1, 1.5 or 2
	Flow Control	RTS/CTS, DSR/DTR, XON/XOFF
	Tx/Rx Modes	Point to Point
Printer Port
Printer Port	Printer Port	1
	Printer Port Protocol	LPT
	Printer Port Connector	25 Pin Female D Connector on Fly Lead
General
General	PCB Layers	4
	Form Factor	Standard Height
	Includes Printer Port	No
	Galvanic Isolation	No
	Power Consumption	awaiting
	Product Weight	0.653 kg
	Product Dimensions	240(l) x 170(w) x 60(h) mm
	Packaged Weight	0.653 kg
	Packaged Dimensions	200(l) x 135(w) x 80(h) mm
	GTIN (barcode)	837324002911
Operating System Compatibility
Operating System Compatibility	Operating Systems	Microsoft Windows 8 32 bit & 64 bit Editions Microsoft Windows 7 32 bit & 64 bit Editions Windows Server 2008 32 bit & 64 bit Editions Windows Vista 32 bit & 64 bit Editions Windows XP 32 bit & 64 bit Editions Linux
Interface
Interface	PCI Express x1, x4, x8 & x16 lane slots	PCI Express (Peripheral Component Interconnect Express), officially abbreviated as PCI-E or PCIe, is a computer expansion card standard introduced by Intel in 2004. All Brainboxes PX cards are PCI Express Base Specification 1.1 Compliant.

Product Attributes

Weight	0.653 kg
Dimensions	200 × 135 × 80 mm
Ports	4 x RS232 + 1 x LPT Printer
Protocol	RS232 + LPT Printer

2203
Ports: 4 x RS232 + 1 x LPT Printer
Protocol: RS232 + LPT Printer
