UC-475

Name: UC-475 2 Port RS232 PCI Serial Card with LPT Parallel Printer Port - Brainboxes
SKU: UC-475
Price: 148.43 USD
Availability: InStock

2 Port RS232 PCI Serial Card with LPT Parallel Printer Port

PDF Datasheet Download

$148.43

Add to Cart

Buy from Reseller

Volume Purchase?Request a Quote

windows-server-2003-32-bit-64-bit-editions

windows-server-2008-32-bit-64-bit-editions

Universal PCI providing one RS232 serial port, one LPT printer port and an optional RS232 port on a fly lead. Data transfer rates up to 115,200 baud rates and the 128 byte deep transmit and 128 byte receive FIFOS, coupled with 1Mbit/s line drivers deliver uncompromising performance on your PC.Includes drivers for all Windows 32 bit and 64 bit Operating Systems, including Windows 8.

Serial Port
Serial Port	Ports	2
	Protocol	RS232
	Connector	DB9 Connector - 9 Pin Male
	UART	Brainboxes 16C958
	UART Compatibility	16750/16550/16450 backwards compatible as well as an enhanced 950 mode
	Tx FIFO Size	128
	Rx FIFO Size	128
	Operating Distance	EIA - RS232 Standard
	Cable	Optional 1 port LPT on fly lead (CC-032)
Serial Port Settings
Serial Port Settings	Max Baud Rate	115,200
	Data Bits	5,6,7 or 8
	Parity	Odd, Even, None, Mark or Space
	Stop Bits	1, 1.5 or 2
	Flow Control	RTS/CTS, DSR/DTR, XON/XOFF
	Tx/Rx Modes	Point to Point
Printer Port
Printer Port	Printer Port	1
	Printer Port Protocol	LPT
	Printer Port Connector	25 Pin Female D Connector on Fly Lead
General
General	PCB Layers	4
	Form Factor	Standard Height
	Includes Printer Port	Yes
	Galvanic Isolation	No
	Power Consumption	195mA @ 5V, 15mA @ 12V
	Product Weight	0.083 kg
	Product Dimensions	136(l) x 120(w) x 18(h) mm
	Packaged Weight	0.194 kg
	Packaged Dimensions	160(l) x 135(w) x 45(h) mm
	GTIN (barcode)	837324000528
Operating System Compatibility
Operating System Compatibility	Operating Systems	Microsoft Windows 10 Microsoft Windows 8 32 bit & 64 bit Editions Windows Server 2012 Microsoft Windows 7 32 bit & 64 bit Editions Windows Server 2008 32 bit & 64 bit Editions Windows Vista 32 bit & 64 bit Editions Windows XP 32 bit & 64 bit Editions Microsoft Windows 2000 DOS
Interface
Interface	PCI 3.0	Peripheral Component Interface

Product Attributes

Weight	0.194 kg
Dimensions	160 × 135 × 45 mm
Ports	2 Ports
Form Factor	Standard Height
Protocol	RS232

1882
Ports: 2 Ports
Form Factor: Standard Height
Protocol: RS232
